The orbital cavity, commonly known as the eye socket, is a complex bony structure that protects the eye and its associated structures. Understanding its anatomy is crucial for ophthalmologists, optometrists, and anyone studying human anatomy. This article provides a detailed look at the bones that form this crucial cavity.

The Seven Bones of the Orbit

Seven bones contribute to the formation of the orbital cavity. These bones articulate in a precise manner to create a strong, yet surprisingly lightweight, protective shell for the eye. Let's explore each bone individually:

1. Frontal Bone

The frontal bone forms the superior wall and part of the medial wall of the orbit. Its contribution to the orbital roof is significant, providing substantial protection from above. The supraorbital foramen, a small opening in the frontal bone, allows passage for the supraorbital nerve and artery.

2. Zygomatic Bone

This bone, also known as the cheekbone, forms a substantial portion of the lateral wall and the inferolateral rim of the orbit. Its strong structure provides significant support and protection to the eye from the side. The zygomaticofacial foramen, found on the zygomatic bone's anterior surface, transmits the zygomaticofacial nerve.

3. Maxilla

The maxilla is a key bone contributing to the orbital floor (inferior wall) and medial wall. The infraorbital foramen, located on the maxilla, serves as a passage for the infraorbital nerve and vessels. This bone's involvement in the orbital floor makes it susceptible to fractures, which can lead to orbital floor blow-out fractures.

4. Palatine Bone

This bone contributes a small portion to the medial wall of the orbit. It's located posteriorly and inferiorly. Its contribution, although small, completes the complex architecture of the orbital cavity.

5. Sphenoid Bone

The sphenoid bone plays a vital role, contributing to the posterior wall, medial wall, and part of the superior wall of the orbit. The optic canal, a crucial opening within the sphenoid, allows passage for the optic nerve and ophthalmic artery, highlighting the importance of this bone's integrity. The superior orbital fissure, also found in the sphenoid, transmits crucial cranial nerves and ophthalmic veins.

6. Ethmoid Bone

The ethmoid bone contributes significantly to the medial wall of the orbit. This intricate bone features thin, delicate structures, including the lamina papyracea, which is surprisingly vulnerable to fractures. The ethmoid bone also contributes to the medial orbital walls. The anterior and posterior ethmoidal foramina allow passage for the anterior and posterior ethmoidal nerves and vessels.

7. Lacrimal Bone

This small, delicate bone is located in the medial wall of the orbit, forming part of the orbit's medial wall. It houses the lacrimal groove which contributes to the lacrimal drainage system.

Clinical Significance of Orbital Bone Fractures

Fractures involving the bones of the orbit are relatively common, especially those affecting the orbital floor (blow-out fractures). These fractures can lead to various complications, including:

Enophthalmos: The eyeball sinks into the orbit.
Diplopia (double vision): Due to muscle entrapment or damage.
Infraorbital nerve paresthesia: Numbness or altered sensation in the cheek area.

Accurate diagnosis and appropriate management are crucial for optimal patient outcomes. Imaging techniques such as CT scans are essential in assessing the extent and location of orbital fractures.

Further Exploration

This article provides a fundamental overview of the bones composing the orbital cavity. Further research into the intricate details of the foramina, fissures, and their clinical significance is encouraged for a more comprehensive understanding of this complex anatomical region. Consulting anatomical textbooks and online resources will enhance your knowledge of this fascinating area.
